100G QSFP28 SR BiDi 100m LC Optical Transceiver

Lane signaling rate 106.25Gb/s with PAM4 Up to 40km transmission on SMF EML Laser and APD receiver 4x25.78Gb/s with NRZ electrical interface (CAU1-4) Support KP4 FEC inside the module High speed l/0 electrical interface l2C interface with integrated Digital Diagnostic monitoring QSFP28 MSA package with duplex LC connector Single +3.3V power supply Power consumption <4W Operating case temperature: 0 to +70 °C Compliant to 802.3cu,SFF-8636&SFF-8679 standar Compliant to 100G Lambda MSA100G-ER1 Optical Specifications Complies with EU Directive 2015/863/EU

Transmission data rate up to 11.2Gbps per channel QSFP+ MSA compliant Compliant to IEEE 802.3ba specification for 40GBASE-ER4 links 4 CWDM un-cooled DFB lasers, using ITU G.694.2 wavelength grid at 1271, 1291, 1311 and 1331nm High Sensitivity APD-TIA with optical DEMUX Up to 60km reach over standard single mode fiber Hot pluggable electrical interface Operating case temperature 0°C to +70°C 3.3V power supply RoHS 6 compliant（lead free）
